Triangle unilateral rubber track undercarriage for crawler fire-fighting robot chassis

Short Description:

The undercarriage is designed for fire-fighting with triangle rubber track.

It is braking by hydraulic system,load capacity is 0.5-15 tons.

Unilateral design gives robot manufacturers more flexible use in size.


Product Detail

Product Tags

Product Details

Fire-fighting robots can replace firefighters to carry out detection, search and rescue, fire extinguishing and other work in toxic, flammable, explosive and other complex situations. They are widely used in petrochemical, electric power, storage and other industries.

The flexibility in and out of fire-fighting robot is completely realized by the mobility of its undercarriage, so the requirements to its undercarriage are very high.

The triangular tracked undercarriage designed and manufactured is braking by hydraulic system. It has the characteristics of lightness and flexibility, low ground ratio, low impact, high stability and high mobility. It can steer in place, climb hills and stairs, and has strong cross-country capability.



Product Parameters

Condition: New
Applicable Industries: Fire-fighting robot
Video outgoing-inspection: Provided
Place of Origin Jiangsu, China
Brand Name YIKANG
Warranty:   1 Year or 1000 Hours
Certification ISO9001:2019
Load Capacity 1 –15Tons
Travelling Speed (Km/h) 0-2.5
Undercarriage Dimensions(L*W*H)(mm) 2250x300x535
Color Black or Custom Color
Supply Type OEM/ODM Custom Service
Material Steel
MOQ 1
Price: Negotiation

Standard Specification / Chassis Parameters

parameter
Type

Parameters(mm)

Track Varieties

Bearing(Kg)

A(length)

B(center distance)

C(total width)

D(width of track)

E (height)

SJ080 1240 940 900 180 300 rubber track 800
SJ050 1200 900 900 150 300 rubber track 500
SJ100 1380 1080 1000 180 320 rubber track 1000
SJ150 1550 1240 1000 200 350 rubber track 1300-1500
SJ200 1850 1490 1300 250 400 rubber track 1500-2000
SJ250 1930 1570 1300 250 450 rubber track 2000-2500
SJ300A 2030 1500 1600 300 480 rubber track 3000-4000
SJ400A 2166 1636 1750 300 520 rubber track 4000-5000
SJ500A 2250 1720 1800 300 535 rubber track 5000-6000
SJ700A 2812 2282 1850 350 580 rubber track 6000-7000
SJ800A 2880 2350 1850 400 580 rubber track 7000-8000
SJ1000A 3500 3202 2200 400 650 rubber track 9000-10000
SJ1500A 3800 3802 2200 500 700 rubber track 13000-15000

Application Scenarios

1..Robot, fire-fighting robot ,transport vehicle

2. bulldozer, digger, small type excavator

Packaging & Delivery

YIKANG track roller packing:  Standard wooden pallet or wooden case
Port :  Shanghai or Customer requirements.
Mode of Transportation: ocean shipping, air freight, land transportation.
If you finish the payment today, your order will ship out within the delivery date.

Quantity(sets) 1 - 1 2 - 3 >3
Est. Time(days) 20 30 To be negotiated

One- Stop Solution

Our company has a complete product category which means you can find everything you need here. Such as rubber track undercarriage, steel track undercarriage, track roller、top roller、front idler、sprocket、rubber track pads or steel track etc.
With the competitive prices we offer, Your pursuit is sure to be a time-saving and economic one.
